Brake Drums&discs Lathe T8465

Product Overview

Description

This machine is a kind of lathe. It can fulfill the reparation of the brake drum, disc and shoe of auto-mobiles from mini-car to heavy trucks. The unusual feature of this equipment is its twin-spindle each other perpendicular structure. The brake drum/shoe can be cut on the first spindle and the brake disc can be cut on the second spindle. This equipment has higher rigidity, accurate workpiece positioning and is easy to operate. This equipment is fit up with out-board supporter to advance loading. Capability of first spindle. Besides, this equipment is fit up with set of crane which turn loading and unloading a heavy break drum into easier. If you adopt this equipment, it can help your enterprise set up higher reputation due to better. Process quality and lower your process cost.



Model	T8465
Drum dia. Capacity	Φ180-Φ650 mm
Disc dia. Capacity	≤Φ500 mm
Spindle speed (3 steps)	25, 40, 70 r/min
Toolpost travel	250 mm
Feed rate	0.16 mm/r
Motor	1.1 Kw / 1400 rpm
Overall dimensions (L× W× H)	800×875×940 mm
Packing dimensions (L× W×H)	1330×960×1230 mm

































Packaging & Delivery

Packaging Details: box

Port:shanghai

Lead Time:

Quantity(Pieces)	1 - 100	>100
Est. Time(days)	15	To be negotiated
