480 ton injection molding machine price
- Category: Plastic Injection Machines >>>
- Supplier: Zhangjiagang,Shen,Zhou,Machinery,Co.,Ltd.
Share on:
Product Overview
Description
Injection Moulding Machine SZ-4800A
5-point twin toggle clamping system by modular optimization software designing. Strong clamping with rapid and stable, to meet the strict clamping condition.
Technical Parameter | ||||
Item | Unit | Parameter | ||
INJECTION UNIT |
|
| ||
screw diameter | mm | 70 | 75 | 80 |
screw L/D ratio | L/D | 22.6 | 21 | 19.7 |
theoretical shot volume | cm*3 | 1346 | 1545 | 1758 |
shot weight(ps) | g | 1225 | 1406 | 1600 |
injection pressure | Mpa | 201 | 175 | 154 |
theoretical injection rate | g/s | 370 | 423 | 484 |
plastic capacity | g/s | 60.4 | 71.4 | 83.7 |
CLAMPING UNIT |
|
| ||
max.clamping force | KN | 4800 | ||
max.opening stroke | mm | 770 | ||
space between tie bars | mm | 760x760 | ||
mould height | mm | 280-790 | ||
max.daylight | mm | 1560 | ||
OTHER |
|
| ||
pump motor power | KW | 45 | ||
pump pressure | Mpa | 16 | ||
heating power | KW | 28 | ||
size | m | 7.5x2.1x2.45 | ||
net weight | t | 20 | ||
oil tank capacity | L | 850 | ||
