IP67 Die Casting Aluminum Waterproof Electrical Enclosure

CHANGHE Enclosures provides users with over 300 choices for packaging electrical and electronics equipment operating in hostile environments. Die-cast in aluminum alloy and resistant to atmospheric and marine corrosion, CHANGHE aluminium enclosure range is designed to house DIN-rail mounted terminal block and various types of sensors. Dimensions range from 50*45*30 mm to 600*310*180 mm. Our enclosures have achieved ingress ratings of IP 67 and IP68 (certain models).

Custom & Modified Enclosures

When a standard enclosure isn’t exactly what you need, CHANGHE can modify our designs for the ideal enclosure solution. Some common modifications we can do for you:

- Mold & Design
- Special Paint Colors
- Silk Screening
- Punched Holes

- Cutouts
- Mounting plate design
- Salt Mist Resistance
- Non-inflammable sealing ring

Product Specs

IP67 Waterproof Aluminium Enclosure 125x80x57mm (11A-38)

The dimensions specified below are Length x Width x Height.

Model No.	External Dimensions	Internal Dimensions	Mounting plate size	Wall mounting size
11A-38	125x80x57mm	117x72x50mm	102x25mm	113x53mm

Technical Features:

· Offers EMC protection
· IP 67 Watertight and dust-proof (IEC60529 : 2001)
· Applied for in tough circumstances: -40°C~120°C
· Impact resistance (IK grade: IK08)
· Paint powder on the surface
· Corrosion resistant
· Body and cover: aluminum alloy
· The interior contains fastening domes to accommodate mounting plates, supporting rails or circuit boards.
· Optional accessories include DIN Accessories, wall mounting kits, mounting plate, cable glands, inner doors hinges.

Product Dispaly

Dimension Chart

Customization

Custom & Modified Enclosures

When a standard enclosure isn’t exactly what you need, CHANGHE can modify our designs for the ideal enclosure solution. Some common modifications we can do for you:

- Mold & Design
- Special Paint Colors
- Silk Screening
- Punched Holes

- Cutouts
- Mounting plate design
- Salt Mist Resistance
- Non-inflammable sealing ring
