SMA Connector Bulkhead Female Solder for RG402 .141

Product Overview

Description

SMA Connector Bulkhead Female Solder for RG402 .141

1. ISO 9001 & IATF 16949 certified

3. RoHS & REACH compliant

4. Made in Taiwan





Features:

1. Broadband performance DC to 18 GHz
2. High mechanical strength, high durability with low VSWR
3. Threaded couplings ensures stability in vibration intensive applications

Applications:

1. Base Stations
2. PC/LAN
3. Instrumentation
4. Telecom

Electronical Specifications

Impedance	50Ω
Frequency Range	0-12.4 GHz on Flexible cable
	0-18 GHz on Semi-rigid cable
Working Voltage	RG-178: 170 VRMS max. at sea level
	RG-316, .085": 250 VRMS max. at sea level
	RG-142, .141": 335 VRMS max. at sea level
Dielectric Withstanding Voltage	RG-178: 500 VRMS max. at sea level
	RG-316, .085": 750 VRMS max. at sea level
	RG-142, .141": 1000 VRMS max. at sea level
VSWR	Straight: 1.3 max., R/A: 1.5 max.
Contact Resistance	Center Contact: 6 milliohm Max.
	Outer Contact: 2 milliohm Max.
Insulator Resistance	5000 megaohms min.





Material Specifications

Parts Name		Material	Finish
Center Contact	Male	Brass	3u" Gold
	Female	BeCu	3u" Gold
Body, Metal Parts		Brass	Nickel or Gold per requirement
Insulators		PTFE	None
Gasket		Silicone Rubber	None
Crimp Ferrule		Annealed Copper	Nickel or Gold per requirement



Note: Other Material/Finish is available on request
