Syringe Barrel Pad Printer

Product Overview

Description

Syringe Barrel Pad Printer

An accurate printing of graduation scale and brand name on the disposable medical products,such as syringe barrel

and test tube.



Techinical data:

a) Production: 150-180pcs/min

b) Dimension: 1500*860*1500

c) Power: 3P+N+PE, 380V+10%. 50Hz. 3.8kw.

d) Weight: Abt.1.5t

e) Air consumption: 200NL/min

f) Environment: dry, clean, 18-26°C





Printing Size	1-2ml	3-5ml	10-20ml	30ml
Printing Speed (pc/min)	230/min	250/min	250/min	180/min
Power supply	220V50HZ	220V50HZ	220V50HZ	220V50HZ
Machine Size(cm)	250x150x200	250x150x200	250x150x200	250x150x200
Power	2.5kw	2.5kw	2.5kw	2.5kw
Weight(kg)	500	500	500	500
Air Pressure	0.2-0.4MPa	0.2-0.4MPa	0.2-0.4MPa	0.2-0.4MPa
