KJ 1400X high temp lab Heat Treatment Oven (1400C Box furnace)

Product Overview

Description

Model: KJ-1400X Heat Treatment Oven

Size: 200x200x200mm (8"x8"x8"), (WxHxD).



Features

1. Operation Temperature: 1300°C (1400°C for short time).

2. Maximum energy efficiency is achieved by surrounding the chamber with thermal-efficient alumina fiber ceramic insulation.

3. Heavy duty double layer structure with cooling fan. Lower teperature in outside case.

4. PID automatic control via current limiting phase angle fired the resistor, e.g. SCR(Silicon Controlled Rectifier).

5. Power control with 30 segments programmable.



Descriptions:


Chamber Size	200 x 200 x 200 mm (8"x8"x8")
Working Temperature	1300°C (continuous)
Maximum Temperature	1400°C
Temperature Control	30 steps programmable and PID automatic control
Heating Rate	0~15°C/min (suggestion: ≤10°C)
Temperature Accuracy	+/-1°C
Heating Element	Silicon Carbide (SiC)
Working Voltage	AC 220V, Single Phase, 60/50 Hz  (or according to your requirement)
Max. Power	5 KW
Outside Size	550 x 650 x 820 mm
Net Weight	115 Kg

Note: there are different chamber sizes for your choice.



Package: Plastic paper inside, Polyfoam filled, Wooden box outside.

Payment: T/T, West union, etc.

Shipping and Delivery: by air/sea, in 15 days after receiving the payment

Warranty: 1 year limited warranty on all electronic parts.
