Name: mixing vessel with bottom mixer
Features:
The equipments are designed and manufactured fully according to the demand of GMP and to standards, such as steel pressure vessels (GB150-2011), and steel welded atmospheric pressure vessels (JB/T4735-1997), etc.
Application
It is applied to liquid preparation and various water treatment process in purgative area,such as infusion solution ,injection solution, eye drop, oral liquid and blood preparation.
Product technical description of mixing vessel with bottom mixer Specification: 30L~50000L Material: SS316L or SS304 Surface finish: inside surface is Ra0.28~0.4μm by mechanical polish. (passivation or electropolish are optional). Outside surface is Ra0.6~0.8μm by satin finish. Agitator: bottom magnetic agitator Pressure: ATM or pressure vessel (-0.1~1Mpa) Structure: Single layer vessel, vessel with jacket, vessel with jacket and insulation Jacket type: dimple jacket, full jacket, or coil jacket Insulation material: rock wool Components: vent filter, temp. gauge, level gauge, manhole, sight glass with lamp and cleaning ball or according to client’s detail requirement. Manufacture standard for pressure vessel: ASME, PED 97/23/EC, GB150-2011
Working volume
Inner
diameter
Outer
diameter
Vessel
height
Total volume
30L
400mm
500mm
400mm
44L
50L
400mm
500mm
600mm
69L
100L
500mm
600mm
650mm
130L
200L
600mm
700mm
1000mm
250L
300L
700mm
800mm
1250mm
370L
500L
900mm
1050mm
1150mm
650L
1000L
1100mm
1250mm
1480mm
1260L
1500L
1200mm
1350nmm
1700mm
1780L
2000L
1300mm
1500mm
1980mm
2200L
3000L
1500mm
1700mm
2150mm
3400L
4000L
1600mm
1750mm
2630mm
4000L
8000L
1900mm
2100mm
3200mm
8300L
The above dimension is only for reference, we can make up to 30000L , and we can make special dimension according to client specific requirement.
Packaging & Shipping
Packaging: wooden case or iron rack
Shipping: by sea or by air
Our Services
We offer design, customization, installation, maintenance services, etc.
Company Information
Shanghai Ritai Medicine Equipment Project Co., Ltd. mainly specializes in innovation and development of sanitary stainless steel pressure vessels, atmospheric pressure vessels, fermenters, valves and piping system which are widely used in the following fields, such as pharmacy, biology, chemistry, food and drinks industry.
Shanghai Ritai is qualified to design and manufacture pressure vessels with the certificates of ASME, PED 97/23/EC, NB, and ISO 9001:2008.
