Basic performance
Protection IP65 (NEMA-4)
Ambient temperature 0~60 °C
Relative humidity 10~95% ( No dews )
Material stainless steel
Size 106mm xφ 20mm ( Length x diameter )
Cable length 1M( standard),3m,15m and particular specifications ( customized)
Electric parameters
Operating power 24 VDC
Max current 20mA
Output signals 0~5V linear , 10 mV/ °C
Measurement parameters 8~14μm
Spectrum range 0~500°C
Optical resolution 15:1
Response time 300ms (95%)
Measurement Accuracy
±1% or±1.5°C% of the measuring value, and the maximum value (environment temperature : 23°C±5)
Repeated accuracy
±1% or±0.5°C% of the measuring value, and the maximum value (environment temperature : 23°C±5)
Launch rate 0.95 fixed (coordinates with special purpose digital display controllers to be able to modify online launch rates)
Basic performance
Protection IP65 (NEMA-4)
Ambient temperature 0~60 °C
Relative humidity 10~95% ( No dews )
Material stainless steel
Size 106mm xφ 20mm ( Length x diameter )
Cable length 1M( standard),3m,15m and particular specifications ( customized)
Electric parameters
Operating power 24 VDC
Max current 20mA
Output signals 0~5V linear , 10 mV/ °C
Measurement parameters 8~14μm
Spectrum range 0~500°C
Optical resolution 15:1
Response time 300ms (95%)
Measurement Accuracy
±1% or±1.5°C% of the measuring value, and the maximum value (environment temperature : 23°C±5)
Repeated accuracy
±1% or±0.5°C% of the measuring value, and the maximum value (environment temperature : 23°C±5)
Launch rate 0.95 fixed (coordinates with special purpose digital display controllers to be able to modify online launch rates)
