seamless nickel pipe for heat exchanger

Product Overview

Description

seamless nickel pipe for heat exchanger



Product Introduction

Item Name	seamless nickel pipe for heat exchanger
Grade	Ni200, Ni201, N4, N6
Standard	ASTM B161 B163, GB/T 2882-2005
Dimension(MM)	OD10-168 xID0.5-10x 100-15000 MM



1.  Metal Chemical Composition:

Grade	Ni+Co	Cu	Si	Mn	C	Mg	S	P	Fe
N4	99.9	0.015	0.03	0.002	0.01	0.01	0.001	0.001	0.04
N6	99.5	0.10	0.10	0.05	0.10	0.10	0.005	0.002	0.10
Ni201	99.0	≤0.25	≤0.35	≤0.35	≤0.02		≤0.01		≤0.40
Ni200	99.0	0.20	0.30	0.30	0.15		0.01		0.40



2.  Metal Mechanical Properties:

Diameter	Tensile strength, min Mpa, pound/in2		Yield strength(0.2%offset) ,min Pound/in2		Elongation in 4D or 4W min,%
	UNS N02200	UNS N02201	UNS N02200	UNS N02201	UNS N02200	UNS N02201
Outer diameter<=5in(127mm	55000 (380)	50 000 (345)	15 000 (105)	12 000 (80)	35	35
Outer diameter <5in(127mm)	55 000 (380)	50 000 (345)	12 000 (80)	10 000 (70)	40	40



Applications



    Heat exchanger coil pipe

    Chemical pipe

    Anti-corrosion equipments

Features



1. Excellent corrosion resistant to turbulently used in condensers for coastal power plants,

    petroleum refineries and chemical plants.

2. High impingement corrosion resistant to brackish seawater at velocities up to 3 to 4 m/sec

    used in desalination plants and other seawater condenser application.

Products Details

Qualificates

FAQ

We need below information to quote for you:



1. What is the dimension of the Nickel pipe? Out diameter? Wall thickness? Total length?
2. Material Grade? Ni200 or Ni201? Or some other Grade?

3. Produce Standard?

4. Application?

5. Quantity?

6. Other requirements?



If you have any interests, please don't hesitate to inquiry.

We welcome the sample orders.
