1.Screened front and rear connector are suitable for cable branch unit ,RMU and pad-mound tranformer,etc. It assures this product to supply electricity for branches.
2.Suitable for fully-submersible connection of size φ 46/ φ 56/91.5/M16bushing (meet for EN50180 and EN50181)
3.Apply to 8.7/15kV,12/20kV XPLE cable,and cable cross section is 35-400mm².
Technical parameter:
For connection of polymeric cable to transformers, switchgears, motors and other equipment with a pre-moulded separable connector. 1. Rated Voltage: 24kV 2. Rated Current: 630A 3. AC Withstand voltage (5min): 54kV 4. Partial Discharged at 24kV: ≤10pC 5. Conductor cross section (mm²): 35-400mm²
6.Meet to IEC standard.
Characteristics:
1.Fully-insulated,fully-submersible and fully screened product.
2.The distance between the center of assemble front and rear connector is 100mm.Not only meet the mounting space requirement of inflatable type RMU but minimize the structure dimension of distribution branch box.
Packaging & Shipping
Standard package,meanwhile we can pack the goods according to your request. We quote EXW price shenzhen factory,the customer can choose the shipping way by yourself.
Our Services
We do not provide free sample,and we can design and manufacture the product according to your request and drawing. The excellent after-sales service will satisfy you.
Company Information
Guangdong AMPLE Technology Co.,Ltd. is a technology-orentied company ,which is specialized in M.V & H.V cable accessories,and covering the voltage from 6kV up to 40.5kV.
The most professional manufacturer of M.V./H.V. cable accessories in China.
Established in 2004, AMPLETEK has obtained ISO9001 standard.
