TKS 2500LSF AC Semi Automatic Electric Screwdriver(Electric tool electric power tool power tool)
- Category: >>>
- Supplier: Kilews Electric Tools (shanghai) Co. Ltd.
Share on (426986242):
Product Overview
Description
Product Overview
Medium torque Compact Semi-Automatic Electric Screwdriver (electric screw driver for assembly)
1) The power controller features:
a) Model:
b) Input voltage: AC 220V~240V 50/60HZ
c) Output voltage:
d) Outside dimensions:
e) Weight: 600g
f) Remark: RoHS
2) Screwdriver features:
a) Torque range: 0.49-1.76N.m
b) High stability,not impact of Voltage changes,free from fatigue under long-time using
c) Small,light body,specially design for the precise needing of tiny screws
d) Best applied to Small appliances.Electronics,Toys,Processing and assembly industry
1) The power controller features:
a) Model:
b) Input voltage: AC 220V~240V 50/60HZ
c) Output voltage:
d) Outside dimensions:
e) Weight: 600g
f) Remark: RoHS
2) Screwdriver features:
a) Torque range: 0.49-1.76N.m
b) High stability,not impact of Voltage changes,free from fatigue under long-time using
c) Small,light body,specially design for the precise needing of tiny screws
d) Best applied to Small appliances.Electronics,Toys,Processing and assembly industry
FEATURES AT A GLANCE
Economical solution for general assembly
High speed model available
PRODUCT SPECIFICATIONS
No | Item | Data | ||
1 | Torque | 0.49~1.76 N.m | 5~18kgf.cm | 4.4~15.84Lbf.in |
2 | Unloaded Rotation Speed(r.p.m) | 2000 | ||
3 | Torque Adjustment | Stepless | ||
4 | Screw Size Dia(mm) | 2.6~4.0(Machine Screw) | 2.6~3.5(Tapping Screw) | |
5 | Power Consumption | 50W | ||
6 | Weight(g) | 600 | ||
7 | Length(mm) | 267 | ||
8 | Repeatable Torque Accuracy (%) | ±5% |
