HYRL 787 terry towel rapier loom
- Category: >>>
- Supplier: Hangzhou Wiltop Textile Machinery Co. Ltd. [Zhejiang China]Hangzhou
Share on (427623390):
Product Overview
Description
USE:
This loom is used to weave all kinds of spiral satin or small jacquard satin towel for face, tea, bath and floor etc. with the material of cotton, wool and blended yarns.
FEATURE:
HY-747 towel rapier loom is our first generation towel rapier loom. its speed improved 30-40% than the shuttle loom and the noise decreases 10-15dB.automatically controls the weft broken and warp broken. the warping machine complete with it is same with the shuttle loom
MAIN DATAS
Reed width(cm) | 180(74”),200(78”),230(90”),250(100”),280(110”) |
Rotation speed | 200~150 R.P.M |
Weft selection: | 6 colors |
Yarn count | Cotton 7Ne-60Ne wool 12Nm-100Nm chemical fabric 100-650D |
Dia of warp beam(mm) | Φ600 |
Dia of rolling-up(mm) | Φ600 |
Let-off type | positive electric let-off |
Terry rasing type | proucing terry by movable reed |
Height of terry(mm) | steeples adjustment from 2 to 12 times |
Shedding mechmism | upper-places mechmism dobby(24pages of shaft) |
Numbers of heddle frame: | 16 pages |
Electric control | P.L.C |
Power(KW): | 1.8-2.2KW |
Weiht(kg) | 1700-2100 |
Overall size(mm) | 4300×2500×2120(200cm) |
we can manufacture according to customer's requirements .
