Laminated aluminum tapes

Product Overview

Description



1. Application

1.For wire cables;

2.For insulation materials;

3.For telephone lines;

4.For flexible duct;

5.We are manufacturer;

6. For champagne cap;

7. Can supply SGS,Certificate of original,MSDS,Test report,ect;



2. Feature

Good insulativity and shielding effectiveness to reduce attenuation, complying with RoHS standard.



3. Dimensions

Name	Aluminium Polyester Foil(Polyester=Mylar=PET)
Thickness	20u-150u
Width	5mm-1000mm
Inner diameter	38mm(1.5in) or 53.5mm(2.1in) or 76mm(3.0in)
Outer diameter	250mm-650mm
Color	Silver,Blue,Golden



Name:AL+PET
Structure	Thickness(mic)	Weight(g/m2)	Yield(m2/kg)
AL9+ PET12	23mic	43	23
AL9 +PET15	26mic	48	21
AL9 +PET19	30mic	54	19
AL9 +PET23	34mic	60	17
AL12 +PET12	26mic	52	19
AL12 +PET15	29mic	56	18
AL12 +PET19	33mic	32	16
AL12 +PET23	37mic	67	15
AL12 +PET36	50mic	87	12



4.Note

Accept orders of foils with different thickness, length and width.
