Cargo Box Van Trucks, light truck,freezer box van trucks,

Product Overview

Description

MODEL			BJ1049V9JW6-A	BJ1041V8JW5-Z1
CHASSIS	ID NO.		BJ1049V9JW6-A/1222850	BJ1041V8JW5-Z1/1222530
	category		chassis	chassis
	manufacturer		BEIQI FOTON MATOR CO.,LTD	BEIQI FOTON MATOR CO.,LTD
	axle		2	2
	wheel base(mm)		3360	3360
	wheel track(front/rear mm)		1530/1485	1385/1380
	tire size		7.00-16	6.5-16
	tire		6	6
ENGINE	model		BJ491EQ2	BJ491EQ2
	manufacturer		BEIQI FOTON MATOR CO.,LTD	BEIQI FOTON MATOR CO.,LTD
	delivery capacity(ml)		2237	2237
	fuel		gasoline	gasoline
	rated power(hp)		95	95
	emission standard		GB17691-2005 EURO3,GB3847-2005	GB17691-2005 EURO3,GB3847-2005
FRAME	FRONT	type	steel plate spring	steel plate spring
		quantity	9	7
	BACK	type	steel plate spring	steel plate spring
		quantity	9+8	7+4
CAR LOAD	dimension parameters	overall dimensions(mm)	6150*2150*3050	5425*1910*2950
		L*W*H
		interior cargo body dimensions(mm)	4380*2050*1900	3655*1810*1900
		L*W*H
		cubage(m3)	17	12.5
		front overhang/rear overhang(mm)	1085/1690	1085/1540
	quality parameters	approach angle/departure angle(°)	22/21	22/21
		curb weight(Kg)	2690	2490
		rated payload(Kg)	3000	2500
		gross vehicle weight(Kg)	6000	5500
	max. speed(km/h)		95	95
	Persons in cab (persons)		3	3
Bitmap Bitmap other:Power steering wheel,Air brake ect.   chassis model BJ4010 category   manufacturer BEIQI FOTON MATOR CO.,LTD axle 2 wheel basemm) 3200 wheel trackfront/rear mm 1429/1425 tire size 7.00-16 tire 6 engine model N490 manufacturer ANHUI QUANCHAI MOTOR CO., LTD delivery capacityml 2540 fuel diesel fuel rated powerKw) 45.6 emission standard GB 18322-2002 GB 19756-2005() frame front type steel plate spring quantity  7 back type steel plate spring quantity  7+4 car load dimension parameters overall dimensionsmm) 5995*1910*2245 L*W*H interior cargo body dimensionsmm) 4250*1810*400 L*W*H quality parameters  approach angle/departure angle(°) 21/22 curb weight(Kg) 1690 payload capacity(Kg) 3500 max. speed(km/h) 85 Persons in cab (persons)  3
