D SUB DB 9P Female Type Connector plug

Material specification

Housing:

high temperature plastic, UL9V-0 Rated

Housing colors:

black/ white/ blue/ grey

Contact:

Phosphor Bronze/ Brass

Shell:

Brass, plated with Tin or nickel

Connector type:

right angle, machined pin

Tail construction type:

Dip type/ SMD type

Mating options:

4-40threaded riveted
4-40threaded riveted &Jack screws assembled
4-40 threaded riveted& jack screws in bulk

Jack screws assembled

Mating options:

2-prong board locks

Electrical Performance

Voltage Rated:

125V AC/DC

Current Rated:

1.0A AC/DC Max

Dielectric strength:

500V AC for 1 minute Between adjacent terminal, no breakdown

Insulation Resistance:

1000Megohm Min 500VDC for 1 minute between adjacent terminal

Contact Resistance:

20 milliohm Max

Operation temperature:

-25°C-85°C

Packing:

Tray packing
