Product Overview

Description



Product Description




Specification


CYLINDER DIAMETER
2.5~6.5 INCHES
NEEDLE COUNTS
60-240N
FEEDERS
4-18 FEEDERS
OUTPUT
15-50METER PER HOUR
POWER
0.75KW
SPEED
110RPM
PACKAGE
80CM*90CM*136CM
MOTOR
220V/380V


CYLINDER STEEL-INLAID SHEET TREATMENT
Steel -inlaid sheet Material imported from Germany, hardness up to HRB65
the Rockwell harness of ordinary cylinder is below HRB60, so ordinary cylinder is easy to break down when the machine works with
pin collision failure.
Cylinder insert steel sheet not easily damaged
Vacuum quenching for cam
The cam material is Cr12MoV, Vacuum quenching, Rockwell harness up to HRB65.
It is not easy to hit needle when it's running on the Cam.
The commom Cam matere is 60Mn, quenched by oxygen, with low hardness. so it will impact needles easily when machine works
Serous conditions can damage the cylinder
Synchronized pulley drive
Synchronized pulley drive is more stable than pulley drive.
The rewinding device is mounted on the lower frame,when working , it will not affect the operation of the cylinder, if the machine
does not get off the lower frame, the rewinding device can only be installed under the cylinder, when working, the rewinding
device will pull the cylinder , thus, the concentricity of the cylinder is affected.


Packing & Delivery




To better ensure the safety of your goods, professional, environmentally friendly, convenient and efficient packaging services will be provided.
