Non asbestos Woven resin brake lining in roll

BBHM   Woven Resin Brake Roll Lining

Wear Performance

Interface
Temperature

Friction
Coefficient

Wear  Rate

(cm³/N·m)

100°C

212°F

0.40—0.65

≤0.7×10-7

150°C

302°F

0.35—0.65

≤1.1×10-7

200°C

392°F

0.30—0.60

≤1.3×10-7

Certificate

ISO9001:2008

Material

Viscose Fiber, Glass Fiber, Brass Wire, Melamine Resin.

Working Condition

Temperature ≤200°C,  Pressure ≤1.0mpa

Application

Heavy Machine, Engineering Plant, Mining Machine,

Conveyor, Anchor Winch, Windlass, etc.

Specification

Thickness(5mm-30mm)×Width(≤600mm)×Length(10m, 15m, 20m), Or on request

Comparative

Advantage

Natural Fiber→Green Products, Corrosion Resisting, Abrasion Resisting.

High Tensile/Breaking Strength, Fatigue Resisting.

Remarks

The information listed here is for the regular product. We take special orders according to your request, such as special specification, color, appearance, even the specific performance, etc.
