mini ice maker (high cost performance)

Product Overview

Description

AZ-20B Mini Ice Maker Specification

Model: AZ-20B

Electrical: 100-120,220-240V/50-60Hz/1 phase

Power: 210W

Finish: Black Painting cabinet,

Stainless steel door and handle

Ice type: Cube

Ice scoop: Yes

Body: Foaming body and door

Max. Ice Production: 20kg/24h

Max. Ice Storage: 12kg

Refrigerant: R134a

Condenser Unit: Air-cooled

Net Weight: 37kg

Gross Weight: 46kg

Product Dimensions:

(W/D/H)370mm/600mm/842mm( not include handle)

Packing Dimensions:

(W/D/H)413mm/665mm/1000mm

Ice making Type: Water-Flow

Control Type: Electronic control

Installation: Built-in or free standing

Load Qty. in Container of 20’/40’/40HQ: 96/202/298Pcs.

Orien AZ-20B Mini Ice Maker Advantage:

1) Adopting world famous brand compressor (ACC,Cubigel,Danfoss,LG,Elextrolux,Zanussi)with strong heat exchange capacity by wind cooling ensures the machine system in excellent performance.

2) Adopting flowing-water ice making mode makes the ice cubes plump and lowers the requirements for the water,no spare water and no drainpipe, save water.
3) With the body and the door made of polyurethane foam,excellent insulation, store ice long time

4) Automatic error detecting function:when error appears ,the system will automatically switch into the error-correcting mode to ensure the operation of ice making .

5) Special cleaning mode: the user can clean the unit according to the needs ,and the water inside the pipe can be drained completely which makes more hygienic.

6) No condensation and save energy
7) Particular automatic heat preservation function
8) Exactly automatic ice making and havesting and easy to use
9) The thickness of ice is adjustable
10) Clear ice
11) Adjustable foot and easy to install
12) The door is reversible.
13) Luxury appearance
