SADT SA40 Ultrasonic Thickness Gauge which can test through coating

Product Overview

Description

SA40+ thickness meter is controlled by micro-processor based on the ultrasonic measuring principle. It is able to measure the thickness and acoustic speed of various materials transmitted ultrasonic. It is designed to measure the thickness of normal metal materials and metal materials covered with coating.



Details:



Display 4 digits LCD



Backlight Yes



Measuring range 0.80~300.0mm in steel with standard probe (Normal mode)

3.00~20.00mm in steel Thickness for coating: <1.2mm (ME mode)



Resolution 0.80~9.99mm ±0.05

10.00~99.99mm ±(0.5% H+0.01)

100.0~300.0 ±(1% H+0.1)



Unit mm/inch

Velocity 1000~9999m/s



Coupling indicator Yes



Calibration Auto



Memory 400data

Low battery indicator Yes



Working environment 0~40oC, 20~90%RH



Power off Auto

Power supply AA battery x 2

Net weight (g) 245



Dimension (mm) 124x67x30



Standard probe PT-5



Optional probes XT-5 / GT-5 / CT2.5
