Industrial Brake lining in roll, Asbestos free Woven Resin Brake Lining, brake lining for elevator

Product Overview

Description

BFH-M Non asbestos Woven Resin Brake Lining in Roll



Color: as per your request

Thickness: 5-30mm;

Width: ≤600mm;

Length: as per your request



Material: viscose fiber, glass fiber, copper wire, melamine resin



Work condition: 200°C, Pressure: 1.0 mpa



Standard: GB/T11834-2000



Application: widely use in decelerating and braking of engineer machines, industry machine and mining machines.



Performance: good elasticity, high tenacity, shock resisting, heat resisting, good duality and anastomosis, agile brake, etc.



We can manufacture the color, length and material as per your request



 Wear Performance of Woven Resin Brake Lining in roll

Interface Temperature	Friction coefficient	Wear rate(CM3/NM)
100°C	0.40—0.65	≤0.7×10-7
150°C	0.35—0.65	≤1.1×10-7
200°C	0.30—0.60	≤1.3×10-7
