Acid Recirculation System for Battery Formation
- Category: >>>
- Supplier: Zibo Torch Machine Co. Ltd.
Share on (498250943):
Product Overview
Description
Product Description
Acid Recirculation System for Battery Formation
Application:Use for the formation of flooded battery .
System component: Acid preparation and storage module, Acid circulation module, Acid filtering and cooling module, Scrubber,
Electrical control module
The maximum load of each circuit: 576 / 2V
Working Pressure: ≤ 1.0Mpa
Acid Temperature: ≤ 50°C
Chemical Cycle: ≤ 38H (traction batteries)
Equipment Power: 10KW
Solenoid valves and electrical components controlling voltage: DC24C
Characteristics:
1. With the acid circulation system, the battery production cycle can be reduced by 3- 4 days.
2.The quantity of the battery can be set according to the technical requirements. (Maximum 576 pieces)
3.With the acid heat exchange, water cost can be reduced, in order to save energy.
4.The tank formation and plate drying process are replaced by acid circulation in order to reduce the plate size.
5.The problems caused by the cold joint during the welding formation process.
6.The acid circulation works in sealed negative pressure condition, no mist overflow, no pollution, good environmental
performance.
7.The battery produced by the acid circulation, the active material is totally converted, the battery are of good consistency.
8.The system pressure and acid transferring speed can be adjusted according to the battery temperature.
9.After collecting, the hot acid can be filtrated, to ensure the cleanliness and temperature of the acid.
Initial capacity of the battery can be increased by 10%.
10.PLC controlling system works with high precision, it is reliable and stable.
11. During the acid circulation process, the acid density can be adjusted, to ensure the electrolyte density of the battery.
12.Cycling equipments, acid filling devices, acid mixing devices can be simplified, in order to reduce the investment cost.
Specification
item | value |
Place of Origin | China |
Shandong | |
Condition | New |
Machine Type | auto |
Video outgoing-inspection | Provided |
Machinery Test Report | Not Available |
Marketing Type | Ordinary Product |
Warranty of core components | 1 Year |
Core Components | PLC |
Brand Name | Torch |
Voltage | 380v |
Power | 15kw |
Dimension(L*W*H) | 13*3*5m |
Certification | iso |
Warranty | 1year |
Key Selling Points | Easy to Operate |
After Warranty Service | Video technical support, Online support, Spare parts, Field maintenance and repair service |
Local Service Location | None |
Showroom Location | None |
Applicable Industries | Manufacturing Plant |
Weight (KG) | 10000 |
After-sales Service Provided | Engineers available to service machinery overseas |
No. of cells | 576 pieces/2v |
Formation cycle time | 38H |
Acid temperature | 50℃ |
Weight | 7000kgs |
Raw material | pvc/pp/ ucpvc |
Application fields | acid formation |
Advantage | High Production Efficiency |
Control system | Siemens PLC+HMI |
Final products | formed battery |
