Chinko Profile Corrugated Roofing Sheets DANA Steel uae

Product Overview

Description

DANA Steel ( A division of DANA Group) ,is one of the largest manufacturers and exporters of single skin corrugated profile sheets.Our profile sheets are made inan ISO 9001:2008 Quality controlled environment.



DANA Steel Processing Industry llc is manufacturer and supplier of steel profile sheets for roof , wall , cladding parkings , fencing , warehouse , sheeting .

10,000 Square meter Factory in UAE – ISO9001:2008 Certified Company in UAE

Specification :-

1. PRFOILE SHEET of 35/150 , 45/150 , 45/250 and other patterns available
2. Steel sheets of thickness 0.30 mm till 1.50 mm are available
3. all RAL Colors available – standard off white , blue , red , light blue
4. Steel , aluminum sheets rolled as per customer choice and drawings

Specification :-

Aluminium profiled sheet is 0.40 mm. up to 1.50 mm. thick Alloy A3105 - H16 Temper is supplied as standard.However different Alloys like ( 3003,3013,4343,4045, 5052,5086,6061, 8011 etc) & Tempers (H12,H14,H16,H18,H20,H22,H24,H32,H34,H36,H38 etc)can be supplied on request.

Galvanized (GI) & Alu Zinc(AZ) coated steel profile sheets 0.30 to 0.90 mm thick as per ASTM A 653 for GI & ASTM A 792 for Alu Zinc - Alternative grades Can be supplied on client request

The Surface is painted with baked regular modified enamel polyester(RMP), with 5 micron primer and 20 micron coat on the weathering side and 5/7 micron primer on the reverse - PVDF, Silicon, Modified Polyester, Platisol & special coatings are available on client request.
