Korea Best Nano Tech Floor Construction PTC Heating Film Hotel Dormitory Office Floor Easy to Install

Product Overview

Description



Nano-Tech PTC Infrared Heating Film “XiCA”

Best Choice! XiCA Heating Film











As the leading heating film manufacturer in Korea, it is our goal to help you meet your business and home heating requirements.



This is why we have designed and created our own heating film called XiCA.



RexVa's Heating Film is a low cost material for under floor heating and, as there are no by-products, it has the added bonus of being eco-friendly.



Our Heating Film products run silently, require little maintenance and are very reliable.



Why is RexVA superior to other products?



1. Achieved many certificates which can provide advanced marketing to customers.
- UL, CU, TUV, CE, RoHS ,etc. Please check the certifications in our hompage : //www.rexva.co.kr/home_en/qua02_01.php

[ Ctrl + Enter ]

2. Achieved many test reports, guaranteed the product quality.
- LVD, EMC, durability, product life, dustproof waterproof, shock, far infrared ray, negative ion, etc. Please check the test reports in our hompage : //www.rexva.co.kr/home_en/qua03_01.php

[ Ctrl + Enter ]

3. Heating film no resistance change due to long-term use.
- Excellent technology with patent registered printing equipment
- During production, our air drying chamber can hold 70meters of heating film at the same time to drying of carbon and silver fully and removing the moisture in carbon , other manufacturer can only make the air drying chanmber under 10 meters . Please check the production process information in our hompage : //www.rexva.co.kr/home_en/man01_06.php

[ Ctrl + Enter ]
This is the reason Why heating film resistance does not change . Please refer to the life term test report in : //www.rexva.co.kr/home_en/qua03_01.php

[ Ctrl + Enter ]

4. Silver on heating film resistance keep stable.
- Silver resistance keep stable in 0.3 ~ 0.4 Ω , in the other hand , other companie’s silver resistance value are in 0.5~21.2 ohms. . Please check the silver resistance value in our hompage : //www.rexva.co.kr/home_en/man01_02.php

[ Ctrl + Enter ]

5. Provide the test report for each production when the product leaves the factory.
- Product Specifications
- Heat test result Please check our test instrument in homepage :

//www.rexva.co.kr/home_en/tec02_01.php

[ Ctrl + Enter ]

6. Conducting Tensile strength test for per production roll.
- Only the product rolls which can pass the Tensile Strength Test can be shipped.

7. The production capacity in the industry is the best.
- Keep the production capacity to be 3 times more than other companies in one month.
- Bulk orders, early delivery available

8. Independent reseach and development of PTC carbon paste to ensure the stability and safety of the product .
- Registered patent for PTC carbon paste
- Using self-developed carbon paste formula and unique PTC carbon paste recipe . Please check our PTC ink manufacturing information in

Homepage, //www.rexva.co.kr/home_en/tec01_01.php

[ Ctrl + Enter ]

9. Acquired UL electric safety certification for PTC products
- First PTC UL semi-product certification in heating film industry

Please check the certifications in our hompage : //www.rexva.co.kr/home_en/qua02_01.php

Below is a cross section of our XiCA PTC heating film products.



You can see how the XiCA heating film is structurally composed:









XiCA Heating Film Specifications :



Below is a table listing models and measurement details for our Heating Film products here at Rexva.



Please take the time to read through them and contact us for any questions.





Model	Width	Thickness	Packing	Weight	Power		Temp	Usage
	(Cm)	(mm)	(m/Box)	(Kg)	(w/m)	(w/sqrm)	(℃)
XT305	50	0.338	150	37	110	220	40~50	General Heating Purpose
XT308	80		100	40	180
XT310	100		100	48	220
XM305-S	50		150	37	110
XM308-S	80		100	40	180
XM310-S	100		100	48	220
XM305-N	50		150	37	110	220
XM308-N	80		100	40	190	230
XM310-N	100		100	48	230	230
XM305-Ultra	50		150	37	110	220
XM308-Ultra	80		100	40	190	230
XM310-Ultra	100		100	48	230	230
XM305-PTC	50		150	37	110	220
XM308-PTC	80		100	40	190	230
XM310-PTC	100		100	48	230	230
XA305-PTC	50		150	37	120	240
XA310-PTC	100		100	48	240
XM305 H	50		150	37	200	400	60~70	SAUNA









The XiCA Heating Film can be customised to meet your needs regardless of the size, shape or location of your floor space



For example, our heating system can be used in the following spaces:







• Hotels, schoolrooms and dormitories : – Our room heater is ideal in these spaces as all rooms can be controlled via one central thermostat



• Offices and buildings : – Improved air quality resulting from our floor heating system means happier and more productive employees. It also makes space for other vital office equipment and machinery



• Restaurants – Infloor heating systems have been proven to improve air quality, reduce moisture levels and limit the spread of bacteria, helping your restaurant meet health and safety requirements

• Bungalows – For housing where there is no gas line connection, an electric carbon Heating Film represents a viable alternative

• Kindergarten Schools – Give your kids a healthy and safe environment to play in! Our heating system avoids risks such as heat burns and tripping accidents. It also saves space giving them more room for their activities

• Hospitals – Our PTC heating film  provides better air quality than conventional systems. It has also been scientifically proven to help reduce dust mites and the development of viruses and bacteria

• Steel Containers – As long as there is an electricity supply, our Heating Film can be installed in any steel or shipping containers

• Balconies – As it is light and takes up very little space, our Heating Film can easily be adapted to your balcony space without the risk of damaging its structural integrity





Characteristics of the XiCA Heating Film

Energy- and cost-efficiency



XiCA Heating Film cuts costs by up to:

• 30% compared to electric heating


• 60% compared to fuel heating

This is because of our efficient convection heating system which uses carbon elements.



It also maintains a steady temperature which can heat up a room in as little as 4-10 minutes.









Safe Heating - RexVa's Heating Film technologies



Without any open flames, gas, overground pipes or cables, the risk of accidents is greatly reduced.





Easy Installation



RexVa's engineering specialists have a proven track record in effectively reviewing floor layouts, creating detailed specifications, and quickly implementing heating systems with little or no hassle.





We also use a methodical installation process ensuring that your heating systems will require little or no long-term maintenance.



Quiet and clean heating



There are no moving parts and no fuel is burned!



Our Heating Film also guarantees minimal sounds or vibrations while enjoying a warm and quiet atmosphere.





Semi-permanent



As there are no moving parts, the likelihood of a breakdown is greatly reduced.



The material used is reliable. It can stand heavy impacts, and is not affected by cold weather.
