Spare parts for Wall Hung Gas boiler

Product Overview

Description

Model	STV-LM39-10mm
Torque	100N
Response time <depend on RPM>	Low -> High : 12sec High -> Low : 8sec
Max Strocke	10mm
Motor	Synchronous Motor, 3.3 / 4 RPM, 50 / 60Hz
Watt	3W
Voltage	Standard : 220VAC (Option : 24VAC, 110VAC)
Insulation	More than 500 MΩ (between electric wire and body by DC 500V Megger)
Withstand voltage	1,500VAC/1min (between electric wire and body)
Ambient temperature	-25 ~ 70 ℃
Electrical connection	RAST 2.5
Weight	138.5g
