| Model | STV-LM39-10mm |
| Torque | 100N |
| Response time <depend on RPM> | Low -> High : 12sec High -> Low : 8sec |
| Max Strocke | 10mm |
| Motor | Synchronous Motor, 3.3 / 4 RPM, 50 / 60Hz |
| Watt | 3W |
| Voltage | Standard : 220VAC (Option : 24VAC, 110VAC) |
| Insulation | More than 500 MΩ (between electric wire and body by DC 500V Megger) |
| Withstand voltage | 1,500VAC/1min (between electric wire and body) |
| Ambient temperature | -25 ~ 70 ℃ |
| Electrical connection | RAST 2.5 |
| Weight | 138.5g |
