The plastic sheet extruder is mainly used to produce plastic sheet of PP, PS and PE. Then the sheet can be taken to produce such as disposable cups, jelly cups, plastic packing containers, file and so on. We adopt advanced international technology and make considerable innovations on design, manufacturing and accessories for NUP series plastic sheet extruder.
SPECIFICATIONS
Model
ZHP-800B
150kg/hr
ZHP-800B
250kg/hr
ZHP-800B
350kg/hr
Width of Die Head
800 mm
800 mm
800 mm
Material
PS, PP, PE
PS, PP, PE
PS, PP, PE
Width of Sheet
PP, PE: 720mm
PS: 650-680mm
PP, PE: 720mm
PS: 650-680mm
PP, PE: 720mm
PS: 650-680mm
Three Roller Size
Dia. 350*800mm*3
Dia. 450*800mm*3
Dia. 450*800mm*3
Thickness of Sheet
PP, PE: 0.3-2.5 mm
PS: 0.15*2 mm
PP, PE: 0.3-2.5 mm
PS: 0.15*2 mm
PP, PE: 0.3-2.5 mm
PS: 0.15*2 mm
Screw Size
Diameter 110 1:32
Diameter 115 1:32
Diameter 120 1:34
Total Power
90 kw
115 kw
145 kw
Working Power
55 kw
70 kw
85 kw
Speed
15-20m/min
15-30m/min
15-50m/min
Capacity
150kg/hr
250kg/hr
350kg/hr
Dimension
12*1.6*2.2m
12.5*1.6*2.2m
13*1.6*2.2m
Weight
5800kg
6800kg
7500kg
