EN CW706R Admiralty Brass Tubes

Share on (50029516743):


Price:

Quantity:


Product Overview

Description


 " EN CW706R Admiralty Brass Tubes  "






Product Description













C44300 Admiralty Brass Rods





c44300-admiralty-brass




The copper based C44300 Admiralty Brass alloy is ideal for manufacturing heat exchanger tubes. The alloy is manufactured to cater engineering requirements and find applications mainly in oil and gas industries that also require its non corrosive properties.

Applications :

  • Industrial Evaporator Tubing

  • Heat Exchanger Tubing

  • Condenser Tube Plates

  • Distiller Tubes

  • Oil Well Pump Liner

  • Ferrules

  • Bourdon Tubes

  • Condenser Tubes






Equivelent Specifications



























SPECIFICATIONSDESIGNATION
ISOCuZn28Sn1
EuropenCuZn28Sn1As
BSCZ 111
JISC 4430
RussianL62-1


Chemical Composition:































 AsCuFePbSnZn
Min/Max0.02 - 0.0670.0 - 73.00.060.070.8 - 1.2Rem
Nominals0.040071.0000--1.000028.0000


Fabrication Properties



















































Joining TechniqueSuitability
BrazingExcellent
Butt WeldGood
Capacity for Being Cold WorkedExcellent
Capacity for Being Hot FormedFair
Coated Metal Arc WeldingNot Recommended
Gas Sheilded Arc WeldingFair
Machinability rating30
Oxyacetylene WeldingGood
Seam WeldNot Recommended
SolderingExcellent
Spot WeldGood


Specifications



































End ProductSpecification
Plate, CladASTM B432
Plate, Condenser TubeASME SB171, ASTM B171
TubeASTM B135
Tube, CondenserASME SB111, ASTM B111
Tube, FinnedASME SB359, ASTM B359
Tube, U-BendASME SB395, ASTM B395
Tube, WeldedASME SB543, ASTM B543


Physical Properties































































Product PropertyUS CustomaryMetric
Coefficient of Thermal Expansion11.2 ·10-6 per oF (68-572 F)20.2 · 10 6? per °C (20-300 C)
Density0.308 lb/in3 @ 68 F8.53 gm/cm3 @ 20 C
Electrical Conductivity25 %IACS @ 68 F0.146 MegaSiemens/cm @ 20 C
Electrical Resistivity41.5 ohms-cmil/ft @ 68 F6.9 microhm-cm @ 20 C
Melting Point Liquid US1720 F938 C
Melting Point Solid US1650 F899 C
Modulas of Elasticity in Tension16000 ksi110000 MPa
Modulas of Rigidity6000 ksi41370 MPa
Specific Gravity8.538.53
Specific Heat Capacity0.09 Btu/lb/°F @ 68 F377.1 J/kg · °K at 293 K
Thermal Conductivity64.0 Btu · ft/(hr · ft2 ·°F) @ 68 F110.8 W/m · °K at 20 C


Sizes Available



































HOLLOW RODSMin Bore Size 20 mm and Max OD 100 mm
ROUND RODS6mm To 130 mm
HEX5mm To 60mm
SQUARE4mm To 60mm
FLAT5mm Min Thickness and max Width 120mm
PROFILES / SECTIONSAS per Customer Drawing
BILLETSUp to 200mm
INGOTSAS per Specification











Company Information





About Us


Established in the year 1989, Shree Extrusions Limited has earned a prestigious position as a manufacturer, supplier and exporter of Extruded Profile in Non Ferrous Metals. Our never-ending list of products includes Aluminum Bronze Rods, Nickel Silver Wire, Aluminum Bronze, Copper Alloy and Brass Rod. Moreover, we also offer Brass Wire for Leaded Ball Pen Tip, Nickel Silver Wire for Ball Pen Tip, Brass Wire, Aluminum Silicon Bronze Rod and Naval Brass. We have been able to earn the accolades of many renowned organizations such as Govt. of India Ministry Defense, Hindustan Shipyard Ltd, Naval Dockyard and Ship Building Centre owing to the international level of quality.

Though, our products are acclaimed worldwide but we have built a strong client base in Asian Countries. Our well established infrastructural setup is located in Jamnagar, Gujrat. The use of latest technologies such as Spectrometers (spark as well as ERF X-Ray Fluorescence) and Electronic & Computerized UTM makes us offer world-class quality products. The entire range products offered by us are valued for its excellent performance, longer service life, economical prices and high tensile strength. These are mostly used in architectural fittings, hardware, electric components, forged components, industrial valves, defense components and pump rods. We fabricate our range of products using high-grade raw material such as virgin non ferrous metals, scraps and
turning.



Our mentor, Shri Radheshyam L. Kabra has more than 35 years of experience in the domain, enabling him to proficiently manage our organizational activities. Under his able guidance, we have been able to achieve enviable market credibility.











Certifications













We offer finest range of extruded non ferrous metals & metal profiles, which are appreciated all through the Asian countries. Due to hard-work and premium quality products, we have earned the certificates & approvals from the following prestigious organizations:



  • Govt. of India Ministry Defense

  • Our Laboratory has been approved by SQAE(AR), Mumbai

  • Garden Reach Shipbuilders & Engineers Limited, Calcutta

  • Material Organization Mumbai, Vishakhapatanam, Khambhalia

  • Hindustan Shipyard Ltd., Vishakhapatanam

  • Mazagon Dock Limited, Mumbai, India

  • Naval Dockyard, Mumbai

  • Ship Building Centre, Vishakhapatanam


Applications Areas


Our range of aluminium extruded profiles in non ferrous metals finds applications in various areas given below:



  • Defense components

  • Naval components

  • Bearing cages

  • Condensed components

  • Marine hardware

  • Propeller shaft

  • Architectural fittings

  • Hardware

  • Electric components

  • Forged components

  • Industrial valves

  • Pump rods


Along with the standard specifications, we also suffice custom order of clients to meet special applicability.
