development board FPGA SPARTAN 3S50

Product Overview

Description

VLS-07 is a FPGA based VLSI Board for implementing various digital design for any Embedded applications.

Feature

·         Supported Piggy Bag Modules:

      -    Piggy Bag  XILINX SPARTAN XC3S50 FPGA (optional)

      -    Piggy Bag  XILINX SPARTAN XC3S400 FPGA (optional)

·         Memory : 1MB ROM for configuring FPGA

·         Indicators

      -    16 input toggle switch with LED indication to indicate logic low and logic high

      -    16 LED for output indication.

·         Onboard Interfaces

      -    4 Digit Seven Segment Displays

      -    16x1 Alphanumeric LCD Display.

      -    4x4 Keys Keyboard Matrix.

      -    8 Channel ADC using ADC0809.

      -    DAC using DAC0800.

      -    12V SPDT Relay.

      -    Buzzer.

      -    DC Motor.

      -    Stepper Motor.

      -    RS-232C Serial Interface.

      -    Ps2 Keyboard Interface.

      -    USB Interface.

      -    JTAG Parallel port Programmer for Piggy Bag Module.

·         Clock generator

      On-board 20MHz, 10MHz, 4MHz, 2MHz, 1MHz, 200KHz.

·         Power selection : On-board of 5V, 3.3V, 2.5V, 1.5V & 1.2V.

·         Power on Reset and configuration reset key.

·        All IC’s are mounted on IC Sockets.

·         Bare board Tested Glass Epoxy SMOBC PCB is used.

·         In-Built Power Supply of +5V/1.5A, ±12V/250mA

·         Attractive abs plastic enclosures.

·         User's Manual with sample experiments.



OPTIONAL

·         JTAG USB Programmer for Piggy Bag Module
