Piston Air Compressor

Product Overview

Description

Piston Air Compressor

The piston air compressors designed with a wide product range for using many different industrial applications. Compressors produce with mentality that quality is not control of the post production, aware of philosophy of the life from beginning the production phase with the movement focused on user satisfaction is passing through a delicate mechanism of quality control. Compressors are meticulously designed with a password for high performance and long life.



SINGLE STAGE PISTON AIR COMPRESSORS
MODEL	Tank Volume (lt)	Air Suction Capacity (lt/min.)	Pressure (bars)	Number of Cylinder	Cylinder Diameter (mm)	Motor Power (hp)	Dimensions (cm)			Weight (kg)
							W	L	H
TK-25/50	25	100	8	1	50	1(220V)	300	600	600	30
TK-50/50	50	100	8	1	50	1(220V)	360	700	700	38
TK-100/70 M	100	200	8	1	70	1,5(220V)	550	1200	980	92
TK-100/70	100	200	8	1	70	1,5	550	1200	980	92
TK-150/2X60 M	150	300	8	2	60-60	1,5(220V)	550	1300	880	106
TK-150/2X60	150	300	8	2	60-60	1,5	550	1300	880	106
TK-200/2X70 M	200	340	8	2	70-70	2(220V)	550	1500	1050	150
TK-200/2X70	200	340	8	2	70-70	2	550	1500	1050	150
TK-200/2X70-3	200	400	8	2	70-70	3	550	1500	1050	150
TK-300/2X90	300	550	8	2	90-90	4	560	1700	1030	187
TK-300/2X90-5*	300	600	8	2	90-90	5,5	560	1700	1050	190
TK-400/2X110*	400	750	8	2	110-110	5,5	650	1950	1270	280
TK-400/3X90*	400	820	8	3	3x90	5,5	650	1960	1220	303
TK-500/2X110*	500	750	8	2	110-110	7,5	650	1950	1380	326
TK-500/3X90*	500	900	8	3	3x90	7,5	650	1950	1380	326
TK-500/3X110*	500	1150	8	3	3x110	7,5	650	1950	1380	350
TK-500/3X110-10**	500	1270	8	3	3x110	10	650	1950	1380	355
TK-1000/2X110-15**	1000	1500	8	4	2x(110-110)	15	1200	2000	1700	700
TK-1000/3X110-20**	1000	2540	8	6	2x(3x110)	20	1200	2000	1750	710





DOUBLE STAGE PISTON AIR COMPRESSORS
MODEL	Tank Volume (lt)	Air Suction Capacity (lt/min.)	Pressure (bars)	Number of Cylinder	Cylinder Diameter (mm)	Motor Power (hp)	Dimensions (cm)			Weight (kg)
							W	L	H
CK-150/70X60	150	160	12	2	70x60	3	550	1300	880	115
CK-150/70X60 M	150	160	12	2	70x60	3(220V)	550	1300	880	115
CK-200/90X60	200	325	12	2	90x60	4	550	1500	1050	150
CK-300/110X70*	300	425	12	2	110-70	5,5	550	1700	1230	260
CK-400/2X90X60*	440	550	12	3	2x90-60	5,5	650	1950	1320	320
CK-500/2X110X70*	500	750	12	3	2x110-70	7,5	650	1950	1380	360
CK-1000/2X110X70-15**	1000	1500	12	6	2x(2x110-70)	15	1200	2000	1750	720

Air flows mentioned according to ISO 1217 standard  at 20 ° C ambient temperature and 1 bar inlet pressure. Air flow Tolerance: -/+ 6%
* Control box is including.
** Electrical Control box is excluded, should demand separately.
