Best seller Teltonika FMB120 GPS Tracker 2019 model with internal antennas

Product Overview

Description

Teltonika FMB120 GPS Tracker Fleet Management Vehicle Tracking System.

2 Years warranty + 12 months free Online Tracking Software subscription.

Small GPS tracker device with internal GPS/GSM antennas and internal battery.

Car tracking
Parameterized operation (acquire & send)
Integrated scenarios



Overspeeding



Authorized driving (50 iButton keys)



Immobilizer



Online tracking
Low energy consumption in deep sleep mode
Internal GPS/GSM antennas
Internal backup battery
Small size with move sensor



FMB120  is  light  real-time  tracking  terminal  with  GPS/GLONASS  and  GSM connectivity, which is  able to collect device coordinates and other useful data and transfer  them  via  GSM  network  to  server .  This  device  is  perfectly  suitable  for applications  where  location  acquirement  of  remote  objects  is  needed:  fleet management,  car  rental  companies,  taxi  companies,  public  transport,  logistics companies,  personal  cars  and  so  on. In case of losing connection FMB120 can store up to 8000 records, and once the connection is established the device will send stored data via GPRS. So you won't lose your data (coordinates, sensors data and etc.).  FMB120 can perform tasks on remote objects, such as monitoring engine status, controlling truck's door etc.

Application:



Track and trace

Road assistance

International logistics

Personal car's and van tracking

Fleet management



TECHNICAL DETAILS:

GSM:

Quad-band 900/1800 MHz; 850/1900 MHz

GPRS class 10 (up to 85,6 kbps);

SMS (text/data)

GPS/GLONASS:

NMEA protocol compatible. Messages: GGA, GGL, GSA, GSV, RMC, VTG, TXT

32 channel GPS/GLONASS receiver

Not less than -160 dB

Interface:

1 Digital Input Reserved for Ignition Status Monitoring

2 Digital Inputs

1 Analog Input (10V or 30V range)

2 Digital Open-collector Outputs (connecting external relays, LED, buzzers etc.)

1-Wire® temperature sensor

1-Wire® iButton

Motion sensor

Power supply (+10...+30) V DC

Internal GSM antenna

Internal GPS/GLONASS antenna

Integrated backup battery

2 Status LEDs

USB Port

Configuration and firmware upload (FOTA and via USB cable)

Features:

Small and easy to mount case

Internal  GSM  antenna  and  Internal  GPS/GLONASS antenna  allow  mount FMB120  much easier

GPS/GLONASS and I/O data acquisition

Real Time tracking

Smart algorithm of data acquisition (time, distance, angle, ignition and event based)

Sending acquired data via GPRS (TCP/IP and UDP/IP protocols)

Smart algorithm of GPRS connections (GPRS traffic saving)

Operating in roaming networks (preferred GSM providers list)

Events on I/O detection and sending via GPRS or SMS.

Scheduled 24 coordinates SMS sending

5 geofence zones (rectangular or circle)

Auto  Geofencing  created  for  car  towing  detection  and  car  theft  prevention

Deep Sleep mode (less  than  2  mA power  consumption)

FOTA (firmware updating via GPRS)

3  operational  modes (Home,  Roaming,  Unknown)  based  on  operator

Integrated  scenarios:

Over  speeding  to  secure  driver  and  prevent  penalties

Immobilizer  function

Authorized  driving  (1-Wire®  iButton  ID  keys  up  to  50  iButton  keys)use  to prevent  stealing  or indicate  drivers

Trip  start  and  end  detection

FMB120  supports  a  remote  logs  reading

FMB120  supports  remote  diagnostic  logs  functionality  using  GPRS.  Possible issues resolving becomes faster.  Manufacturer can  read  logs  remotely  using  SMS/GPRS  to  diagnose  the  FMB120  and  timely  respond to  the  fault
