USB Biometric Fingerprint Scanner Optical with SDK Portable fingerprint Scanner
- Category: >>>
- Supplier: SARAL INFOTECH
Share on (50039361076):
Product Overview
Description
General Description
The FP is a compact, USB Single Finger Capture Device that captures highly accurate, high quality fingerprint images. The FP is certified as meeting or exceeding minimum FBI interoperability standards that ensure high quality images under the PIV-071006 standard established by NIST. Specifically, the FP is certified for used in the FIPS 201 PIV program as well as FAP 20 Mobile ID implementations. The FP is a USB 2.0 supported device and includes Auto-On™, automatic finger placement detection capability.
Key Features
· FBI Certified for FIPS 201 (PIV) & FAP 20 Mobile ID Compliance
· ICAO Compliant Image Quality
· Auto-On™
· Smart Capture™
· USB 2.0 Hi-Speed Compliant
· Bulk mode transfer
· Programmable serial number
· Multi-Device connection support
· USB bus-powered
· SDKs available for integration into applications
Applications
· PC Peripherals
· PIV Fingerprint Verification Station
· Government Logical Access Control
· Airport Security
· E-Passport Fingerprint Scanner
| Optical |
|
|
|
|
|
|
| Image Sensor | CMOS | |
|
|
|
|
| Image Resolution | 500 PPI | |
|
|
|
|
| Image Size | 300 x 400 pixels | |
|
|
|
|
| Platen Size | 18.2 mm x 22.9 mm | |
|
|
|
|
| Effective Sensing Area | 15.24 mm x 20.32 mm | |
|
|
|
|
| Image Grayscale | 256 levels (8-bit) | |
|
|
|
|
| Light Source | Red LED | |
|
|
|
|
| Lifetime (typical) | 60,000 hours | |
|
|
| |
|
|
| |
| Electrical |
|
|
|
|
|
|
| Supply Voltage | 5.0V DC + 5% via USB | |
|
|
|
|
| Current Consumption (max) | 150 mA | |
|
|
| |
|
|
| |
| General |
|
|
|
|
| |
| Dimensions (W x L x H) | 30.0 x 46.6 x 22.2 mm | |
|
|
| |
| Operating Temperature | -20°C ~ 65°C | |
|
|
| |
| Operating Humidity | 90% RH or less, noncondensing | |
|
|
| |
|
|
| |
| Other |
|
|
|
|
| |
| USB | USB 1.1 Full-Speed and USB 2.0 Hi-Speed | |
|
|
| |
| Image Capture Speed | 0.2 ~ 0.5 seconds with Smart Capture™ | |
| (varies according to finger condition) | ||
|
| ||
|
|
| |
| Operating Systems Supported | Windows 8 / 7 / Vista / XP / 2000 / CE, Server 2008 R2 / | |
| 2003, Linux, Android 3.1 & above | ||
