Network Power ETP48200 Huawei Embedded DC Power System ETP48200 C5A1

Hong Telecom Equipment Service LTD (HongTelecom) & REDLINK TELECOM CO., LTD. (REDLINK) are leading professional equipment distributor and service provider in telecommunication infrastructure and solution field, and now is extending our business to ICT (Information and Communication Technology) field.
HongTelecom & REDLINK offer full range of telecom infrastructure products, our business scope include Router/Switch/BRAS, GPON/EPON/FTTX, Optical TRANSMISSION(SDH/DWDM/PTN/Microwave), DSLAM/PSTN/MSAG/MSAN, Firewall/Security Gateway, Power Energy/UPS/indoor Outdoor Cabinet, Video Conference, WLAN etc., We also supply used and refurbished wireless and core network, including Huawei/Ericsson/ NSN/Alcatel/ZTE, GSM/UMTS/LTE, BBU, RRU, BTS.

Product Introduction

Network Power ETP48200 Huawei Embedded DC Power System ETP48200-C5A1

Huawei EmbeddedPower System ETP48200

ETP48200  ETP48200-A5

ETP48200-C11A1

ETP48200-C5A1  ETP48200-C5B4  ETP48200-C5B6  ETP48200-C5B7  ETP48200-C5C4  ETP48200-C5D6

ETP48200-C5A1 and ETP48200-C5A3 are AC/DC embedded power system with excellent performance such as high power efficiency, intelligent battery management, remote monitoring, wide range of AC input voltage, etc. The system configures 50A of 1U height rectifier modules, and provides up to 200A output current. ETP48200-C5A1 and ETP48200-C5A3 can be embedded in 19-inch rack or cabinet.

• Wide range of AC input voltage from 85V to 300V
• Wide operation temperature range of rectifier from -40ºC to 75ºC
• Online-swappable rectifier provides easy installation and maintenance
• Standard installation structure design, adapting to various scenarios
• Compact design, saving space and installation cost
• High rectifier efficiency over 96% helps to save energy
• Excellent rectifier dormancy function helps to increase system efficiency
• Intelligent battery management and protection helps to prolong battery lifespan
• Support environment monitoring and remote management through dry contact, serial interface or Ethernet interface

Electrical Specifications	Specification
Input
Input Voltage	380VAC/220VAC
Input mode	220/380VAC 3-phase or 220VAC Single phase
AC Input Frequency	45~66Hz, rated value: 50Hz/60Hz
Input capacity	1×63A/3P
Output
DC Output Distribution
Output voltage	42~58VDC, rated value: 53.5VDC
Output power	12kW
Others
Dimension	482.6mm(W)×330mm(D)×219.5mm(5U, H)
Weight	≤20kg (without rectifiers)
Cooling	Natural cooling
Environmental Specifications
Operating temperature	-40°C to 65°C
Storage temperature	-40℃~+70℃
Operating humidity	5%~95%(non-condensing)
Altitude	0~4000m (If the altitude is within the range of 2000m to 4000m, the maximum operating temperature decreases by 1ºC as the altitude increases by 200m.)
