122*122mm IR Ceramic Infrared Heater Panel Ceramic Heater 1000W

Product Overview

Description



Ceramic heater is also called far-infrared ceramic heater. It generates heat through heat conduction and heat radiation, and has a certain penetrating power. Ceramic infrared heater panel use conductor containing more than 95% silicon and quartz glass hich can resist 1800°C as main material. They create infrared radiation after chemical reaction. The spiral Cr20Ni80 resistance wire is cast into the conductor. With its advantages in thermal efficiency, radiation, safety and energy conservation,infrared ceramic heater widely used in: vacuum blister machine, coating machine, automobile interior molding machine, medical equipment and smokeless barbecue oven, etc.



Dimension	240 x 60, 240 x 80, 120 x 120, 120 x 60, 60 x 60 etc.
Shapes	Trough, Hollow and Flat
Insulation Material	Ceramic
Conductor Material	Nichrome Wire
Voltage	220 volts, 380 volts, 110 volts
Wattage	250 watts - 1000 watts
Lead Connection	Ceramic Bead Lead Wire 150mm
Thermocouple	Optional, K or J Type
Operating Temperature	300C - 700C
Recommended Radiation Distance	100mm - 200mm
Color	White,Black,Yellow,Pink, Green
