Spiral Wire Looping and Welding Machine for Ventilation Fan

Product Overview

Description



 Spiral Wire Looping and Welding Machine for Ventilation Fan





Automatic spiral fan guard welding machines are usually comprised of automatic spot welding machine for frame, outer ring welding machine, spiral wire looping & welding machine, ring bending machine, butt welding machine for ring, etc.



The key machine for industrial fan guards is the spiral wire looping and welding machine. It is our special design, combining spiral wire looping and welding together, stable quality and high productivity.



After manually putting guard framework onto the looping die (some frameworks are welded already, some are just in pieces), this machine can automatically loop spiral wire first, and then automatically weld spiral wires with frameworks.



The upper welding torch is servo drive, automatically move radially and weld one frame wire, then auto return back to origin for next frame wire welding.



The side welding torch(s) is pneumatic driven, controlled by PLC, also full automatic.



For different size industrial fan guards, you should change different looping die and change looping pitch settings on HMI (touch screen)
