Fast Delivery Metal Case 6 Port AI PoE Switch 4 Port 10/100Mbps PoE Support Vlan QoS 250m Extend
- Category: Network Switches >>>
- Supplier: Shenzhen Fengrunda Technology Co. Ltd.
Share on (50045808134):
Product Overview
Description
Metal Case 6 Port AI PoE Switch 4 Port 10/100Mbps PoE Support Vlan QoS 250m Extend
Product Description
AI104 is 6 port intelligent PoE switch with 4 working modes, AI VLAN mode, AI Extend mode, AI power mode, AI QoS mode. By default, all ports are free to communicate; when AI VLAN mode is enabled, 1-4 ports are isolated from each other, which can effectively suppress network storms and improve network performance. In the AI Extend mode 1-4 ports can effectively transmit distances up to 250 meters, which is suitable for remote monitoring and power supply. In the AI power mode, the switch automatically detects the working status of the PD device and finds that the abnormal device automatically restarts the device. In the AI QoS mode, when the device is congested, the video data is processed preferentially to make the video smooth. The device supports the standard IEEE 802 af/at protocol, which can automatically detect and identify the PDs that comply with the IEEE 802 af/at standard and provide power for them, so there is no need to worry about PoE or non-PoE devices that can damage private standards.
Key Features
AI Extend: 1-4 ports support 250 meters long distance power supply (should be use cat5e or cat6 cable)AI VLAN: Isolating ports 1-4 to each other can effectively suppress network storms and improve network performance.
AI QoS: Customize application priority to improve network sensitivity. For example, video priority, monitoring transmission is more smooth
AI power: Automatically detect the power receiving port, find the dead device, power off and restart the device
Support wireless access points (APs) and network surveillance cameras via Cat 5 cables;
Support IEEE802.3af/at standard PD device;
Supports uplink port auto-flip (Auto MDI/MDIX)
Adopt store-and-forward exchange mechanism
Intelligent power supply, lowest power consumption, ensure the power demand of the PD terminal
With power circuit protection, it can protect the security of the back-end equipment;
Zero configuration feature power is automatically supplied to the adaptive device;
No fan design to achieve energy saving and environmental protection;
Support port no link power saving function;
Technical specifications
Network Port | · 4 10/100Mbps PoE RJ45 port ( Port 1~ port4) |
· 2 10/100Mbps RJ45 port uplink(Port5~port 6) | |
Transfer Rate | · 100Mbps full Duplex, 10 or 100Mbps Half Duplex |
Network protocol and standard | · IEEE 802.3i, IEEE 802.3u, IEEE 802.3x, IEEE 802.3af, IEEE 802.3at |
Performance | ·Bandwidth: 1.2Gbps (no block)) |
· Network delay(100 to 100M bps): maximum 20 μs (using 64 byte packet) | |
·Frame filtering and transmission rate: | |
10M port maximum 14,800pps | |
100M port maximum 148,800pps | |
LED indicator | · Power |
· LINK/ACT | |
POE pin | 1/2(+), 3/6(-); |
Power | ·Max power for single port36W . |
·External power adapter: 60W; | |
Dimensions | ·Size(LxWxH): 125mm x 75mm x 27mm |
·Weight: 0.5kg | |
Environment | ·Operating Temperature: 0°~40°C |
·Operating Humidity: 10%~ 90%, Non-condensing | |
EMC | · CE Class B |
· FCC Part 15, Class B | |
· VCCI Class B | |
· C-Tick | |
Safety regulation | · CE/ROHS/FCC/CCC |
Certifications
Company Information
Shenzhen Fengrunda Technology Co., Ltd (HORED) is a global leader in PoE devices supply. Established in 2011, we has been committing to R&D on PoE devices and solutions, we have obtained many national patents. We offer full line products and high quality and cost-effective solutions. Besides PoE switches, produces also covers ethernet switches, power line communication, wireless access points.
We are devoted to research & design, production & processing, sales & marketing, integrating global resources to keep us a leading position. HORED is a worldwide leading brand in network and communication field.
At present, we use chipset solution is Broadcom, RTK, TI(Texas Instruments) etc.
Our factory size about 3,000 square meters, No. of production lines above 10. Production capacity is 2000pcs every week, total employees 201-300 people.
QC department seriously control all products quality from material to finished products. Our product can be inspected by the third inspection part, all the products passed certificate, FCC, RoHS, CE...
Honesty is the business basis.
Packaging & Shipping
Shipping Methods:
Shipping By Sea or Air.
Shipping By Express DHL / UPS / FEDEX / TNT / EMS.
Shipping By Customer's Agent.
Our payment terms: T/T HSBC, Western Union, Alipay (Escrow).30% deposit and 70% balance before shipping.
FAQ
A.What's the after-sale service?
a.One year warrnty or negotiable
B.Why choose Fengrunda (HORED)?
a.Prompt delivery and remarkable services
b.Competitive selling prices
c.Rich experience of OEM&ODM co-operation , accept orders according to coustomers demands
d.We have R&D team, our product has been approved by IOS9001, CE, FCC and ROHS etc.
C.How about Minimum Order?
a.To satisfy customer's requirements, we accept sample oder, even one piece
