Quickly production 20m straight arm platform lift hand truck for sale
Main technical parameters of the product
Product Name: Aerial Work Truck
Dimensions (mm): 7950x2100x3250
Total mass (kg): 6810
Rated mass (kg):
Service quality (kg): 6485
Front suspension/rear suspension (mm): 1015/2470
Approach/Departure (°): 24/12
The maximum speed (km/h): 105
Emission standard: EURO IV
Chassis parameters
Fuel Type: Diesel
Number of axes: 2
Wheelbase (mm): 3815
Shaft loading: 2090/4720
Cab ride number: 2+3
Front wheel distance (mm): 1504
Rear wheelbase (mm): 1425
Number of springs: 8/6+5
Number of tires: 6
Tire specifications: 7.00-16 14PR, 7.00R16 14PR

Description of the vehicle: widen the front bumper with the chassis option; rear extension 650mm; side protection and rear lower protection material Material: Q235, side protection connection: welding; rear lower protection connection: bolt connection,cross-section size (width × height): 30 × 180 (mm), height from the ground: 530mm.

Engine parameters
Engine Model: 4KH1-TCG40
Engine manufacturer: Qingling Isuzu (Chongqing) Engine Co., Ltd.
Displacement (ml): 2999
Power (kw): 88

Dedicated function description
Maximum working height: 20m Maximum working width: 11.5m
1. The use of international leading Qingling high-end chassis to install telescopic arm hydraulic lift special device
2.Environmental protection items to the national phase III emission standards for motor vehicles (National IV)
3. The control system adopts CAN bus technology and computer intelligent automatic limiting device
4. Made of high-strength steel plate, full telescopic working arm, built-in hydraulic drive structure, strong driving force,compact structure, good maneuverability, large operating range, smooth and flexible operation
5.Automatic leveling mechanism, with manual leveling control function, the working platform can be rotated 360 degrees continuously, the bottom plate adopts non-slip steel plate, working bucket rear, convenient for personnel to enter and exit,reduce the vehicle's center of gravity
6.H-type legs, large span, good stability, the legs can be independently retractable, but also linkage, equipped with support leg flashing lights, used for the leg profile during work, issued a light alarm signal
7. Equipped with emergency power source, can achieve emergency car
8.Imported hydraulic valve adjusting boom running speed
9. Electronic control system optional ground wireless remote control operating system
