CNC Portable gas Cutting Machines/portable cutter

Product Overview

Description

We can customize the Beam and Lead rail depends on Users request.



The equipment of CNC portable gas cutting machine adopts the USA technology professional industrial PC, compact structure, reasonable design, with light weight, small size, convenient to move, suitable for indoor and outdoor characteristic

The CNC portable gas  cutting machine is the substitutes of semi-automatic and imitated cutting machines, which can cut any complex planar graph as same as a big gantry CNC cutting machines.



Application: cutting carbon steel (flame cutting)\\stainless steel\\aluminum\\copper(plasma cutting), feeding, especially suitable for abnormity-size’s sheet and batch production.



Technique data

Model	PL-CNCFC/PLCNCPC
Beam Length (X axis)	1000mm-3000mm (Optional)
Lead Rail Length( Y Axis)	1500mm-4000mm (Optional)
Effective cutting Scope	1000mm-3000mm (Optional)
Effective cutting thickness	Flame 6-150mm(Oxygen, Acetylene or Propane)
Input Power, Frequency	Single-phase AC220±10%V/50HZ
Rated Power	180W(Not including plasma power supply)
LCD Size	5.7 Inch
Plasma Torch Height Control	1 piece (Optional)
Cutting speed	0~3000mm/min
Cutting precision	National Standard JB/T10045.3-99
Torch Height Distance	0-100mm
Cutting Mode	Flame/Flame
Combustive Gas	Oxygen + Acetylene or Propane
Display Interface	English/ Other language as your edit
Numerical of Control Torches	1
