Automatic Bottom Locked Cardboard Carton Making machine

Product Overview

Description

Automatic Bottom- Locked Cardboard Carton Making machine



Adopting Panasonic PLC, operable colorful screen, smoothly finishing coverpaper feeding& gluing, board folding, corner sealing, inner box manually positioning,rail-arms picking, coating and flaps bending.Malfunction and parameters setting auto-display.



Timing for glue pre-heating.



Glue circulating pump. Suckers levelling auto-revising. Coating paper feeder.

Conveying belt with air pressure helping better performance of inner-box positioning,
the error range is only ± 0.3mm.



CPU controlling the conveying belt and molding part.Molding part smoothly finishing box pushing, coating and flaps bending.



Adopting low voltage control systems in famous brands like SCHNEIDER, OMRON, SMC
SIEMENS.



 Inner-box 4-corner sealer, sealing 4 corners of an inner-box at the same time(Optioned)

Box max. size:	400 x 300 x 70mm
Box min size:	100 x 40 x 15mm
Coating paper thickness:	1-4mm
Production capacity:	10-25pcs/min
Power:	12.5kw
Weight:	3000kg
Size:	6800mm x 2400mm x 2500mm













FAQ
1.Q:What is the machine warranty?
   A:one year.
2.Q:What is the production time while placing order?
   A:About 30 days
3.Q:What is the delivery time?
   A:Within 30 days after get the payment.
4.Q:Can your company handle shipping for customers?
   A:Yes.(Please provide us your requested seaport and we can check the shipping charge and arrange shipping for your order)
5.Q:Does the packing strong?
   A:Yes, of course! All of our export packing is with strong wooden pallets, all are confirmed  to export packing standard.
6.Q:How about after-sales service process?
   A:When your machine has problem, contact your sales and we will solve your problem as soon as possible.
7.Q:Are you manufacturer?
   A:Yes, we are manufacturer with about 20-year experience and profession.
8.Q:Do you have stock product to sell?
   A:Actually our machine need 20-30 days to manufacture, and there are many orders  from China and foreign countries, so we need custom one for you, and your order will be highly attention to manufacture.
9.Q:Do you inspect the finished products?
     A:Yes, we have QC department, they will inspect the machine before shipping, to
         ensure there is nothing problem of the machine .
