Table power feed for milling machine

Product Overview

Description

Table power feed for milling machine:



1, Using on milling machine, drilling milling machine

2. Easy to instsall , modification need

3. High quality design and construction materials.

4. Circuit penel is designed with easily replacement insert type connectors.

5. Assy-gear (nylon) clutch has built in torque release to prevent damage to shaft and metal gear if too much resistance is met.

Directions of power feed Model Out of torque



 SPECIFICATION OF  Table power feed for milling machine:

Directions of power feed	Model	Out of torque
X axis (longitudinal)	AS235	15N.M(135LBS)
	AS250	17N.M (150LBS)
	AS235 horizontal	15N.M(135LBS)
Y axis (cross feed)	AS235	15N.M(135LBS)
	AS250	17N.M (150LBS)
Z axis (knee-lift)	AS250	17N.M (150LBS)
Speed range	0-135 R.P.M    0-140 R.P.M
Rapid speed	180 R.P.M       200R.P.M





























PHOTOS OF Table power feed for milling machine:
