Full automatic Pneumatic steel wire mesh welder

Product Overview

Description





full automatic steel wire mesh welding machine



The main feature of the full automatic steel wire mesh welding machine as follows,



• Adjustable air cylinder,which can adjust the feeding wire to produce the different distance beteew the weft wire.
• Pantented gasbag,which is clamping firmly,running stable, locating accuratel
•
• PLC control system and touch screen to realize the automatic feeding,welding,cutting.
•
• According to different wire diameters,the second voltage of the welding transformers can adjust freely to welding wire firmly.

 The technical parameters of Full automatic pneumatic steel wire mesh welding machineas follows,





Item	XL-PW-1200A
Mesh Wire Diameter:	2.5-3.0mm or as your requirements
Wire Mesh Hole	50mm*50mm or as your requirements
Mesh width	1200mm or as your requirements
Input Supply	AV380V 50HZ 50KVA
Air Source Equipment	3m3/min, 0.6-08Mpa
Welding strength	≥330N
Lack welding rate	≤2%
Number of Warp	25
Welding Speed	23-26(times/minute)
Machine Weight	1.5T







 we could produce the pneumatic steel wire mesh welding machine as your  requirements. please contact with  us .
