Sell new wet process 300tpd rotary kiln in different production line

1.The general condition:
Rotary kiln is the main equipment for sintering cement clinker.the rotary kilns produced by our company can be divided into dry press and wet process.they can also be used for chemical industry,metallurgy industry and etc.through technical renovations,the rotary kiln sintering system equipment made by our company has adopted high measuring precession,plunger pump,variable speed adjusted valve,contact graphite block air seal and other national advanced technologies.in order to raise up auotmation degree,industrial TV has been used at the kiln head for monitoring of kiln,analog fluorescent screen has been used for display of process flow,infrared scanning system has been adopted for sintering zone to directly reflect the burning conditions on the computer.with the use of these new technologies.it is direct in vision,convienent in operation and reliable in use.therefore,thermal condition can be stabilized and running rate of equipment can be raised.compared to same sized equipment,its running rate has been raised 3-5% up,production has been increased 5-10% and heat consumption has been reduced 15% down.
2.The technical parameter
1.The capacity of 3*88 wet process rotary kiln is 384tpd
2.The slope of the kiln shell is 3.5%
3.The supports of this rotary kiln is 5
4.The speed of main drive is 1.74r/min
5.The speed of auxliary drive is 3.24r/h
6.The main drive type is YSP315M-6,the rated power is 90kW.the speed adjusting range is 1000r/min, the rated voltage is 380V, the type of gear box is YSN1110-711,The total ratio is 71, the type of auxliary drive is Y160L-6, the rated power is 11kW.the rated speed is 970r/min, the rated voltage is 380V.The auxliary gear box type is ZL50-14-II, the total ratio is 31.16
7.The total weight of the rotary kiln is 390t.
1.How to order
Step 1:have intention and send you the standard quotation
step 2:visit and know each other very well
step 3:discuss all the technical details and commertical details
step 4:discuss the contract content
step 5:sign the contract
2.How about the delivery
for whole line.9 months after the advanced payment for the first lot,12 months after the advanced payment for the second lot
for the whole clinkder grinding sattion,6 months after the advanced payment
for the single ball mill,four months after the advanced payment
for the single rotary kiln,six months after the advanced payment
3.Payment
T/T,OR L/C
company information
Jiangsu Pengfei Group Co., Ltd. is one of the leading manufacturers of rotary kiln and grinding equipment in China and the global market. It will be listed on the main board of Hong Kong in 2019. The stock name and code: China Pengfei Group HK03348.
The business scope includes the design, manufacture and service of equipment in the fields of building materials, metallurgy, chemical industry, environmental protection, etc., and as an EPC service provider, providing customized one-stop solutions for design, procurement, construction and trial operation.
The company is committed to the research and development of new technologies such as energy-saving energy storage and comprehensive utilization of resources, and has established innovative research and development platforms such as national enterprise technology centers and postdoctoral workstations. We have completed a number of major equipment projects such as national industrial revitalization, national torch plan, national key new products, and we participated in "Cement Industry Rotary Kiln", "Cement Industry Vertical Mill", "Cement Industry Roller", "Cement Industry Drafting of more than 10 national standards and industry standards, such as the use of tube mills, and technical requirements for complete sets of new dry-process cement production equipment. The leading products are rotary kiln systems, grinding equipment, and cement production lines. The technology is at the leading domestic level in the industry and won the advanced collective of the national building materials industry, the outstanding enterprise in the building material machinery industry for 40 years of reform and opening up, the rotary kiln won the national single championship of the national manufacturing industry. According to Frost & Sullivan's industry report, Pengfei Group is the largest supplier of rotary kilns in China and the world in terms of 2018 revenue. It has completed the construction of more than 100 cement production line projects, exported to more than 70 countries in the world, and has a global footprint. It sells products and provides one-stop solutions to customers in more than 50 Belt and Road countries, such as Bangladesh, Kazakhstan, Turkey, Uzbekistan, etc.
Pengfei people surveyed the University, benefited the world, actively fulfilled social responsibilities, and became an industry leader.
2.Main products
Rotary kiln system, grinding equipment and cement production line.
Rotary kiln system mainly includes rotary kiln, preheater, dryer, cooler and rotary kiln control system;
The grinding equipment system mainly includes tube mill (including ball mill and coal mill), roller press, vertical mill, separator and grinding equipment control system;
Cement production line: Including 1 000 t/d, 2 500 t/d, 3 000 t/d, 5 000 t/d cement production lines and EP/EPC engineering general contracting services of various grinding production lines with annual output of 100,000 tons, 300,000 tons, 500,000 tons, 1 million tons and 2 million tons.
3.Business scope
Building materials field: complete sets of technologies and equipment such as cement, lime, high-phosphorus soil and aluminum-vanadium;
Metallurgy field: laterite nickel ore roasting kiln, lithium ore roasting kiln, gold ore smelting kiln, iron chrome reduction kiln, copper mine furnace, steel pellets,large-scale mining mill, vertical coal mill, etc.;
Chemical field: calcium carbonate, titanium dioxide complete technology and equipment, composite powder complete technology and equipment, nitriding furnace, coal efficient cleaning and upgrading kiln, coal-to-liquid, coal clean-dry distillation technology and equipment, oil sand shale oil extraction technical equipment;
Environmental protection fields: solid waste, hazardous waste, sludge disposal kiln, cement kiln co-processing waste technology and equipment,
