Auto Multi Roller uv vanish coating machine, digital prints uv liquid liminator

Product Overview

Description

Auto Multi Roller uv vanish coating machine, digital prints uv liquid liminator



650 UV coating machine is middle equipment that we manufactured for the digital photo printing factory. It takes place the traditional techniques of cold mounting and hot mounting.  The processed photos have such effects as high definition, high gloss, environment protection. The cost is only 03-0.6RMB per square.



Product model No.	QS-CM480	QS-CM650	QS-CM900
Laminating width	460 mm	650 mm	900 mm
Coating thickness	0-0.1mm	0-0.1mm	0-0.1mm
Laminating thickness	0.2mm-10mm	0.2mm-3mm	0.2mm-3mm
Lamianting speed	200-300 m/hour	150-500 m/hour	200-400 m/hour
Power	3000 W	4000 W	6000 W
Curing model	UV curing	UV curing	UV curing
Power supply	220V\\50Hz	220V\\50Hz	220V\\50Hz
Dimensions (mm)	1150*800*1100	1900*1100*1100	1900*1350*1100
Weight	220 kg	280 kg	380 kg





We are the factory----the advantage of choosing factory.
Better Price
As a factory, you can do business directly with us. It saves the profits of trading company.

Better service
We have our own professional sellers and after sales service team.

Honesty and trustworthiness
We have exported the machines more than 8 years. There is no one trade dispute.
