JS 32 Three Input Tube Cast Iron Oil Rotary Hand Pump For Drum

Product Overview

Description

JS-32 Three Input Tube Cast Iron Oil Rotary Hand Pump For Drum



Features:



Compact and lightweight design for multiple applications

Cast Iron Pump Housing: A high quality material for demanding applications

Suitable For Dispensing Oil: Great for moving oil from larger drum to smaller containers

Also good for gasoline, kerosene, diesel fuel and low viscosity oil

Rain Barrel Compatible

Great manual option for dispensing water from your barrel



Specification:



Suction distance: 1.5m
Lift distance: 5m
Flow rate: 22L/min

Rotative velocity: 70 RPM

Inlet: 32mm

Outlet: 25mm

Pump boday material: Cast Iron

Total length: 126cm



Technical Data:



Model	Suction distance	Lift distance	Flow rate	Carton dimension	Weight
JS-32 with one input tube	1.5m	5m	22L/min	102x20x17cm/5pcs	19kgs
JS-32 with three input tubes	1.5m	5m	22L/min	36x31.5x29cm/4pcs	15.5kgs
