AWS A5.7 ERCuAl A2 aluminum bronze brazing welding wire 1.6mm
- Category: >>>
- Supplier: Taian E.S.K. International Co. Ltd.
Share on (519070749):
Product Overview
Description
Product Description
| NAME: Aluminum Bronze | |||||||||||||
| Physical & Mechanical Properties: | |||||||||||||
Solids-Temperature 1030°C Density7.6kg/dm³ Elongation 35% Liquids-Temperature 1090°C Tensile Strength 390N/mm² Brinell Hardness 140HB | |||||||||||||
| Packaging | |||||||||||||
MIG | Diameter | 0.8 - 2.0mm | Packaging | D100mm D200mm D300mm | Weight | 1kg/5kg/12.5kg/13.6kg/15kg | |||||||
0.030"-5/64" | 2lb/10lb/27lb/ 30lb/33lb | ||||||||||||
TIG | Diameter | 1.6 - 6.4mm | Length | 457mm / 914mm | Packaging | 5kg/box 25kg/box 10kg/plastic package | |||||||
1/16" - 1/4" | 18" / 36" | 10lb/box 50lb/box 10kg/plastic package | |||||||||||
| Intruduction & chemical composition: | |||||||||||||
| Particular suitable for the overlay welding of copper,aluminum,and nickel material with steel. It has increased resistance to wear and abrasion,as well as superior corrosion resistence to seawater. Widely used for ship constructions, apparatus and plumbing. For multilayer welding on steel, pulsed arc welding is recommended | |||||||||||||
Standard | Class | Alloy | Cu | Al | Fe | Mn | Ni | P | Pb | Si | Sn | Zn | other |
GB/T9460 | SCu6180 | CuAl10Fe | bal. | 8.5-11.0 | max | - | - | - | max | max | - | max | max |
1.5 | 0.02 | 0.1 | 0.2 | 0.5 | |||||||||
BS EN14640 | Cu6180 | CuAl10 | bal. | 8.5-11.0 | 0.5-1.5 | 1 | 1 | - | 0.02 | 0.1 | - | 0.02 | 0.4 |
AWS A5.7 | C61800 | ERCuAl-A2 | bal. | 8.5-11.0 | 0.5-1.5 | - | - | - | 0.02 | 0.1 | - | 0.02 | 0.5 |
DIN 1733 |
| SG-CuAl10Fe | bal. | 9.0-11.0 | 0.5-1.5 | max | max | - | max | max | - | max | max |
1 | 1 | 0.02 | 0.1 | 0.02 | 0.4 | ||||||||
Packaging & Shipping
Our Services
Company Information
FAQ
Q: what is warranty time ?
A: 12 months from you got the cargo.
Q: what is delivery time / lead time ?
A: 30 days
Q: what is your minimum order ?
A: 500kgs
Q: what is your payment term ?
30% down payment for order confirmation, 70% before shipment.
