New Clutch Type 2 Wire Central Lock Actuator (JQ CLA 2F)

Clutch type central lock actuator

Universal features, fits any model of any brand

Heavy-duty, high torque motor

Motor with Japanese technology

Covers fixed with screws

Nylon housing

Patented double track design, moving more stable and anti-block

Adjustable positioning hardware for easy installation and quiet operation

Hardware with eight mounting holes for flexible installation

360-degree swivel head

Operating voltage: DC 12V ±10%

Empty-load current: 1.5A ±5%

Stall current: <5A

Load current: 3A + 10%

Pull force: 5.5 KGS + 5%

Push force: 5.0 KGS + 5%

Mechanical life:≥ 100,000 working cycles (one up and down operation as a working cycle)

Electrical life: ≥ 80,000 working cycles ±10%

Travel distance: 22mm ± 0.5mm

Operating pulse: 0.3~0.4 second

Material of actuator case: PA66+GF30

Operating temperature: -30°C~ +80°C

Spec. of motor wire: Ø2.3 26*0.14 copper (AVS 0.41)
