High alumina ball mill
- Category: >>>
- Supplier: Shanghai Gongtao Ceramics Co. Ltd.
Share on (531315798):
Product Overview
Description
High alumina ball mill
Introduction:
Alumina ceramic mill pot is a kind of mill pots which has wear-resistance.We can also supply plain ceramic mill pot:99% ceramic mill pot. The spe:0.5 litre,1.2 litre(standing),1.2 litre(lying),3 litre,5 litre,10 litre,20 litre.
Basic property: | |||
Item | Alumina milling pot | ||
Chemical component | Al2O3 | ≥99 | |
R2O | ≤0.2 | ||
Fe2O3 | ≤0.1 | ||
SiO2 | ≤0.2 | ||
Vol.density(g/cm2) | ≥3.80 | ||
Apparent Porosity(%) | <1 | ||
Bending Strength(Mpa) | >350 | ||
Compression strength | >12000 | ||
Permittivity∑(1MHz) | 2 | ||
Rigidity(HRA) | 88 | ||
Specification & Usage: | ||||
Spe. | Usage | |||
Volume (ml) | Diameter (mm) | Height (mm) | Thickness of wall (mm) | It has good chemical stability and abrasion resistance.It can be applied in crush chemical product,rare-earth material and all kinds of silicate material. |
500~12000 | 105~245 | 200~300 | 7~10 | |
Specification of alumina corundum milling tank C type:
Column corundum milling tank
| Capacity in L | Diameter mm | Height mm | Thickness of wall mm | Thickness of cover mm |
0.3 | 65 | 47 | 10 | 15 | |
0.3 | 90 | 90 | 7 | 15 | |
0.25 | 90 | 40 | 7 | 15 | |
0.5L | 105 | 140 | 7 | 15 | |
0.5 L | 105 | 80 | 10 | 15 | |
1 L | 120 | 120 | 7 | 15 | |
1 L | 130 | 87 | 15 | 15 | |
1 L | 130 | 130/100 | 7 | 15 | |
1 L | 130 | 90 | 12.5 | 15 | |
1 L | 133 | 120 | 10 | 15 | |
1.5 L | 145 | 120 | 7 | 15 | |
4-5 L | 200 | 180 | 15 | 15 | |
4-5 L | 175 | 220 | 8.5 | 15 | |
4-5L | 180 | 215 | 12 | 15 | |
4-5L | 200 | 200 | 15 | 20 | |
12-15L | 250 | 320 | 10-15 | 20 | |
|
|
|
|
|
