18 years factory CNC brush and broom machine

Product Overview

Description

18 years factory CNC brush and broom machine



Product features:

1.This machine is suitable for all kinds of brush of which the diameter between Φ1.8mm and Φ4mm and within the height of bristle is 40mm to tufting;

2.Panel Control System, displays in either Chinese or English, easy to understand;

3.Tufting methods: flat wire style;

4.Largest wool length: 40mm.

5.Models can be stored: 100 (expandable).

6.Input methods: Chinese display, menu-driven operation, handheld encoder or keyboard input.



Technical parameters

Description	Unit		Parameter
Max Speed	Holes/min		≤1200
Hole diameter	mm		Φ1.8-Φ4mm
Spindle quantity	Piece		2-4piece
Journey X axis	mm		300
Journey Y axis	mm		300
Maximum program quantity	Piece		100
Air pressure	Mpa		6
Power voltage, frequency	V, Hz		220V, 50Hz
Machine power	KW		2
Contour size	mm		1200×1350×1830
Weight	KG		1200
Control system		CNC Controller
Disturbance Display		English edition
Safety protection		Overload, short circuit protection
Lubrication		Auto Lubrication System
Main Speed Control		Frequency inverter
Fiber box		Frequency inverter
