Product Overview
Description
| Product model | AQDXW4 | |
| Overall length | mm(in.) | 605(23.8) |
| Overall width | mm(in.) | 200(7.9) |
| Overall heigth | mm(in.) | 945(37.2) |
| Transom heigh | mm(in.) | 417(16.4) |
| Weight | kg | 10 |
| Full throttle operating range | r/min | 3800-5200 |
| Maximum output:kw(HP)@r/min | 1.9(2.6)@5000 | |
| Idling speed (in neutral) | r/min | 1250-1350 |
| Engine type | 2-stroke | |
| Cylinders | 1 | |
| Displacement | cM2 | 50 |
| Bore x stroke | mm(in.) | 42x36(1.65x1.42) |
| Ignition system | CDI | |
| Control system | Tiller | |
| Starting system | Manual | |
| Gear positions | / | |
| Gear ratio | 2.08(27/13) | |
| Trim and tilt system | Nanual tilt | |
| Integral fuel tank capicity | L | 1.4 |
| Separate fuel tank capicity | L | \\ |
| Maximum fuel waste | L/h | 1.4 |
| Engine oilcapacity/withoutoilfilter | L | Fuel:oil ratio:30:1 |
| Gear oil capacity | cM2 | 45 |
| Propeller options* | in | 3-7 1/4"*5" |
