Change over Switch

Product Overview

Description

Changeover Switch, Selector Switch

1. Poles: 2P, 3P, 4P, 5P

2. Rated current: 10A, 16A, 20A, 25A, 32A, 40A, 50A, 63A, 80A, 100A

3. 30°, 45°, 60° or 90° switching angle

4. Forced open contacts

5. Finger protected

6. Fulfills the load break requirements up to 690 V and 1000 V

7. Terminal screws in open position

8. Red operation lever & yellow panel, pad lockable

9. Disconnect Switches offer ideal features for their use as: ON-OFF Switches, geover Switches, Multi-step Switches, Code Switches, Gang Switches, Instrument Switchesand Motor switches

10. Function: Applied in control of machines, lights, protective devices, measurement equipments, as well as control motors.

11. Our products are designed, manufactured and tested according to the following standards: EN 60947, EN 60204-1, IEC 60947, IEC 60204-1

12. Certificate: CE, CB, Semko, ISO9001:2000

13. Samples: provided freely

14. Warranty: 3 years; every item is tested before delivery, professional testing lab in factory

15. Lead time: 20 days and depend on ordering quantity

16. ODM, OEM: acceptable; mould toolings are finished in our own mould tooling center

changeover Switch

Our weather protected isolating switches are suitable for internal any external applications. They can offer complete protection against dust and a heavy sea or a strong jet of water from all directions.



Rotary switch
Features:
1) Current rating: 16A, 32A, 40A, 63A, 80A and 100A
2) Function: changerover

3) Pole:2P,3P or 4P.Please make connection with us without any hesitationif any special specification.
