Item | 1.28KWh | 2.56KWh | ||
Model | HY-1K1B | HY-2K2B | ||
Solar Inverter | ||||
Inverter Output Power | 1KW | 2KW | ||
Output Voltage Waveform | Pure Sine Wave | Pure Sine Wave | ||
Output Voltage | 210V-230Vac 50Hz | 210V-230Vac 50Hz | ||
Bulk Charging Voltage | 29.3Vdc | 29.3Vdc | ||
Total Charging Current(Grid AC+solar) | 20A | 20A | ||
PV Array MPPT Voltage Range | 30Vdc~60Vdc | 30Vdc~60Vdc | ||
Solar Charging Current | 10A Max. | 10A Max. | ||
AC INPUT | 230Vac | 230Vac | ||
AC Charging Current | 20A | 20A | ||
Lithium battery | ||||
Nominal Votage | 12.8V 100Ah(25.6V 50Ah) | 12.8V 200Ah(25.6V 200Ah) | ||
Nominal Energy Cpacity | 1280Wh | 2560Wh | ||
Max.charge current | 60A | 60A | ||
Max.discharge current | 60A | 60A | ||
Operation Temperature | -23℃~+65℃ | -23℃~+65℃ | ||
Certificate | CE IEC62133 UN38.3 MSDS | |||
Product size | 432*190*395 | |||
Warranty | Battery warranty 3 years, inverter 1 year, design life 15 years | |||
