three phase 6w ac reversible induction motor

Product Overview

Description

three phase 6w ac reversible induction motor

SPECS (Cont.Rated)

Model Lead Wire Type		Output Power W	Voltage   V	Frequency   Hz	Current   A	Starting Torque mN.m	Rated Torque mN.m	Rated Speed r/miN	Capacitor   μF
Pinion Shaft	Round Shaft
2IK6GN-AJ	2IK6A-AJ	6	1ph100	50	0.240	55	48	1200	3.5
				60	0.250	50	40	1450
2IK6GN-EJ	2IK6A-EJ	6	1ph110	60	0.160	40	40	1450	2
			1ph 120		0.180
2IK6GN-CE	2IK6A-CE	6	1ph 220	50	0.130	50	48	1200	0.8
			1ph230		0.110
2IK6GN-HE	2IK6A-HE	6	1ph 220	60	0.140	55	40	1450
			1ph 230		0.120
2IK6GN-S	2IK6A-S	6	3ph 220	50	0.076	85	48	1200	-
				60	0.065	70	40	1450



Parallel Shaft Gearhead(Sold Separately)

Gearhead Type	Gearhead Model	Gear Ratio
Long Life Low Noise	5GN*K	3,3.6,5,6,7.5,9,12.5,15,18,25,30,36,50,60,75,90,100,120,150,180,200
	5GN10XK(Decimal gearhead)

Enter the gear ratio in the box(*)within the model name
